OGASSA HORIZON

The OGASSA HORIZON represents the next evolution in aerospace, delivering enhanced endurance, connectivity, and military mission performance for challenging operational environments.

Built on the reliability and field-tested architecture of the previous OGS42 version, the OGASSA Horizon integrates a larger, high-efficiency wing that increases lift capability and aerodynamic performance. It is a military-grade proven UAS that is being used by several forces, including the Portuguese Air Force and Portuguese Navy under Squadron 991 that operates 12 units since 2019 and the Portuguese Navy with x31.

With over thousands of operational flight hours, the OGASSA has demonstrated proven success across a wide range of operational scenarios. The OGASSA HORIZON is a low-maintenance aircraft offering true multi-mission capability. It represents a next-generation tactical UAS engineered to operate farther, longer, and smarter.

NSN Code: 1550-26-201-9600

1400 km

Range ( Full ISR payload )

15 h

Max Endurance

45 kg

Max Takeoff Weight

5.2m

Wingspan

Flight Operations & Launch

OGASSA HORIZON VTOL & CTOL Configuration available

Integrated Technological Architecture

We apply our experience to create a complete set of sensors, datalinks and satellite communications to boost the OGASSA HORIZON performance while still maintaining the capability to integrate third-party systems

Mission Systems & Payload

Electro-optical sensors
- Native integration with UAVision UGS 600 / 600+ gimbal payloads
External Payload hardpoint capability
- Capacity for 4 kg of additional payload under the wings
Ground Control Station ( GCS )
- Operations and telemetry managed via the military G2000B station

Propulsion & Power

Combustion Engine with EFI
- Electronic fuel injection optimized for 10,000 ft altitude
Onboard generator
- Continuous power for mission systems and avionics
Dual battery Backup power
- Backup power via dual battery and dual fuel tank.
Cruising Speed
- 51 kt ( 95 km/h ) with a maximum speed of 70 kt ( 130 km/h )

BLOS Communications

Datalink Principal
- UAVision StormComm ( Range 120km / 65nm )
Satellite Communications ( SatComm )
- Full integration with Starlink & Iridium SBD constellations
Redundant control & data links
- NATO B, C & E
Secure backup datalink
- Encrypted 4G datalink for public, private or military networks

Autonomy & Flight Control

High‑Precision Autopilot
- Doubly redundant inertial and GNSS ( GPS ) systems
Autonomous Operation
- Full ATOL capability ( automatic takeoff and landing )
Structural Safety
- Redundant flight‑control surfaces for survivability

StormComm DataLink

With the integration of StormComm datalink, the OGASSA HORIZON features a complete UAS BLOS gyrostabilized communication system with a 100 km range, proven through testing and operational use by the Portuguese Air Force and Navy.

Achievement

In 2022, the previous OGS42 version, operated by the Portuguese Air Force and UAVision, departed from Beja Airbase on the Portuguese mainland at night and performed a crossing to Porto Santo Island in the Madeira Archipelago, covering a distance of 1,000 km ( 540 nautical miles ).

Flight altitude: 4000 ft

Cruise speed: 51 Knots

Fuel consumption: Half a tank

Please contact us for more information about the OGASSA HORIZON

Our team will be happy to provide the details you need
